GlobalCore 797TC Series
High Tough Cover Constant Pressure 6000 PSI Hydraulic Hose
| Part #: 797TC-24 | Manufacturer: Parker - Hose Products Division |
|
Price/UOM: $103.63
|
Availability: 39,527 |
| UOM: FOOT |
Parker’s Global Core 787TC hose provides 5,000 psi (35 MPa) constant working pressure in all sizes. ½ ISO 18752 minimum bend radius. Flex impulse tested providing a hose superior in both performance and service life. Meets ISO 18752 performance specification.
Email this page to a friend
Product Attributes
| Inner Diameter: | 1.5 Inch |
| Working Pressure: | 6,000 psi (42 MPa) |
| Material: | Tough Cover |
| Mating Fitting Series: | 77 |
| UOM: | FOOT |
| Series: | 797TC |
| Trade Name: | GlobalCore |
| Hose Pressure Range: | High |
| Inch/Metric: | Inch |
| Minimum Bend Radius: | 4 1/2 Inch |
| Distinct Properties: | Tough Cover Constant Pressure 6000 PSI |
| Application: | Hydraulic |
| Working Pressure Range: | 6000 PSI (345 bar) |
| Specification: | ISO 18752 |
| Mating End Fitting Series: | 77 |
| Operating Temperature: | -40°F to +257°F (-40°C to +125°C) |
| Inner Diameter Inch/mm: | Inch |
| Parker Group: | Fluid Connector |
| Parker Division: | Hose Products |
| ISO 18752 Performance: | DC |
Part Number Tags
797TC-24
