Showing 1 - 5 of 5
| Part # | Availability | Price | |
|---|---|---|---|
| 520N-3 | 3,613 | $6.22 | |
| 520N-4 | 10,099 | $6.97 | |
| 520N-5 | 1,327 | $9.32 | |
| 520N-6 | 8,643 | $8.29 | |
| 520N-8 | 5,439 | $10.63 |
| Inner Diameter | Material | Working Pressure | UOM | Mating Fitting Series |
|---|---|---|---|---|
| 0.1875 Inch | Thermoplastic | 5000 PSI (340 bar) | FOOT | 55 |
| 0.25 Inch | Thermoplastic | 5000 PSI (340 bar) | FOOT | 55 |
| 0.3125 Inch | Thermoplastic | 4500 PSI (310 bar) | FOOT | 55 |
| 0.375 Inch | Thermoplastic | 4000 PSI (280 bar) | FOOT | 55 |
| 0.5 Inch | Thermoplastic | 3500 PSI (240 bar) | FOOT | 55 |
Showing 1 - 5 of 5
General Hydraulic Hose meets or exceeds SAE 100R8 Ideal in Hot Water applications not recommended for use over-the -sheave ( pulley system) applications
