| Part # | Availability | Price | |
|---|---|---|---|
| 588N-8 | 284 | $10.96 | |
| 588N-10 | Backorder | $16.02 | |
| 588N-12 | 128 | $16.03 | |
| 588N-16 | 115 | $22.73 |
| Inner Diameter | Material | Working Pressure | UOM | Mating Fitting Series |
|---|---|---|---|---|
| 0.5 Inch | Thermoplastic | 3500 PSI (240 bar) | FOOT | 58 |
| 0.625 Inch | Thermoplastic | 2750 PSI (190 bar) | FOOT | 58 |
| 0.75 Inch | Thermoplastic | 2250 PSI (160 bar) | FOOT | 58 |
| 1 Inch | Thermoplastic | 2000 PSI (140 bar) | FOOT | 58 |
Showing 1 - 4 of 4
High Pressure NON-Conductive meets or exceeds 100R8 Hydraulic circuits replaces 100R2 hose wherever greater flexibility is needed Meets SAEJ517 for less than 50 micro-amps leakage under 75000 volts per ft.
