77 Series 1CA77
Parkrimp Permanent Female BSP Parallel Pipe - Swivel - 90° Elbow (60° Cone)
Email this page to a friend
Showing 1 - 5 of 5
| Part # | Availability | Price | |
|---|---|---|---|
| 1CA77-15-8 | 36 | $47.31 | |
| 1CA77-22-12 | 1 | Call To Place Order | |
| 1CA77-28-16 | 8 | Call To Place Order | |
| 1CA77-35-20 | 104 | $186.53 | |
| 1CA77-42-24 | 91 | $250.99 |
| Hose I.D. | Material | Metric Thread | UOM |
|---|---|---|---|
| 1/2 Inch | Steel | M22x1,5 | EACH |
| 3/4 Inch | Steel | M30x2 | EACH |
| 1 Inch | Steel | M36x2 | EACH |
| 1 1/4 Inch | Steel | M42x2 | EACH |
| 1 1/2 Inch | Steel | M52x2 | EACH |
Showing 1 - 5 of 5
77 Series Parker Fitting is a Parkrimp permanent (crimp) style fitting which permits quick assembly with our family of Parkrimp crimpers. Assembly of No-Skive hose and fittings does not require removal of the outer cover of the hose. This eliminates premature hose failure caused by skiving too long or short.
